Technical Parameter
|
Compressor power |
33 KW |
45 HP |
|
Refrigerant gas |
R507 |
|
|
Content of refrigeration |
3.8 kg |
8.4 Ibs |
|
Condensing medium |
Water |
|
|
Hybrid motor power |
11 KW |
14.8 HP |
|
Feed pump motor power |
0.75 KW |
1 HP |
|
Discharge pump motor power |
0.75 KW |
1 HP |
|
Total power |
46 KW |
64 HP |
|
Air consumption |
2 m³/h |
36 cu.ft./h |
|
Pressure requirement |
6 bar |
87 psi |
|
Air quality requirement |
2.5 |
0.06 g/cu.ft. |
|
oil-free, maximum moisture content |
g/m³ |
|
|
Equipped main circuit breaker |
400 V |
70-80 Amp |
|
Condensate consumption: |
||
|
a) Cooling water+5℃(41℉) |
2,236 Liter/h (598 US gallon/h) |
|
|
b) Running water+15℃(59℉) |
3,359 Liter/h (887 US gallon/h) |
|
|
c) Tower water+30℃(86℉) |
13,446 Liter/h (3,552 US gallon/h) |
|
|
1 1/4" |
|
|
1 1/4" |
|
|
1 1/2" clamp |
|
|
1 1/2" clamp |
|
|
160% |
|
Feature
- The maximum production capacity is 1500 L/h.
- The A1500 freezer is a continuous and automatic ice cream freezer.
- The mixing pump and the ice cream pump are gear pumps.
Advantage
- The design and the materials of pumps are selected carefully to reduce wear, and the gap of pumps can be adjusted according to normal wear. The pumps are driven by the gear motor controlled by the frequency transformer.
- The A1500 automatic and continuous ice cream freezer can be upgraded to meet various requirements of special needs, ingredients, and capacity.
- The control panel provides clear and intelligible information for operators by displaying graphics and text to reduce the difficulty of the operation.
Application
- Suitable for manufacturers who need a medium ice cream production.
- Suitable for manufacturers who need to upgrade the freezer to meet special demands
- Suitable for manufacturers who need the freezer with an air flowmeter equipped.
Packing
The sealing structure freezer A1500 is usually secured in a wooden box and is fixed on the baseplate of the transport box. When completing the devanning operation, please move the box closer to the installation site.
After receipting the freezer, make sure that the wooden box is moved as close to the operating site as possible. The transmission of the freezer can be performed by a forklift or crane (placing the lifting structure of crane under the bottom plate).
The wooden box can be transported by forklift (1) or crane (2).
FAQ
Q: What is the production capacity of the A1500 freezer?
Q: What is the size of the A1500 freezer?
Q: What parameters can be adjusted and monitored by the touch screen panel controlled by the PLC?
Ice cream temperature
Flow
Viscosity
Overrun
Cylinder pressure
introduction
Runchen Machinery Co., Ltd. is a mechanical equipment manufacturing company which serves the ice cream manufacturers. In the development process, Runchen always insists on the principle of "Quality First, Reputation First, Customers First". The company is located in Jiangsu province and there is a strong technical team and a sales and service team in the company. Runchen has innovated continuously for over seven years and developed a great many types of product, as well obtained many patents. Therefore, Runchen has a good reputation both in domestic and foreign markets.
Runchen henceforth will more emphasis on improving the quality of products and services, and improving the enterprise culture, perfecting internal management mechanisms to provide greater quality of products and services for customers.
