Technical Parameter
|
Technical items |
Parameters |
Remarks |
|
Built-in compressor |
4.5 KW |
|
|
Refrigerant gas |
Standard R507 |
|
|
Content of the refrigerant |
2.8 Kg (6.17 LB) |
|
|
Condensing medium |
Water |
|
|
Mixing motor |
0.75 KW |
|
|
Hybrid motor |
0.37 KW |
|
|
Total power |
6 KW |
|
|
Air consumption |
0.5 m³/h |
|
|
Compressed air consumption |
6 bar |
|
|
Compressed air mass, maximum moisture content |
2.5 g/m³ |
|
|
Condensed water consumption: water in water pipe |
≤+20℃ |
800 L/h |
|
Condensed water inlet connection |
Inner diameter 16mm hose |
|
|
Condensed water outlet connection |
Inner diameter 16mm hose |
|
|
Mixture feed tube, outside |
19 mm |
3/4" clamp |
|
Ice cream discharging tube, outside |
25 mm |
1" clamp |
|
Maximum overrun ratio |
100% |
Feature
- The maximum production capacity is 50 L/h.
- A continuous and automatic ice cream freezer.
- All function buttons are controlled by the HMI and easy to use.
- Operators can set parameters like the ice cream flow, overrun ratio, viscosity etc. through the HMI. Through calculating, the built-in PLC can automatic control functions of every part of the freezer to produce the needed ice cream product.
Advantage
- The automatic design greatly reduces labor costs.
- We have stock of A50L automatic and continuous ice cream freezer, so the machine can be shipped quickly.
- Automated design can reduce labor costs and make operations convenient and fast.
- Powerful features and low price.
Application
- Suitable for manufacturers who need to produce 50L ice cream per hour.
- Suitable for manufacturers who need to control the production process by the HMI.
- Suitable for manufacturers who need to produce ice cream automatically without manual production.
Packing
The freezer, which is designed as a self-sealing machine, is usually packaged in a wooden box and fixed on the baseboard. The unpacking operation should be processed near the installation site.
The wooden box which carried the A50L automatic and continuous ice cream freezer should be moved near to the operating site as far as possible when receiving. The transport of the freezer can be done by forklift or crane (place the lifting structure under the baseboard).
The wooden box can be transported by forklift (1) or crane (2).
FAQ
Q: How to use the A50L industrial automatic and continuous freezer?
Q: How does the freezer work?
Q:What should the temperature of the freezer be set to?
The output slurry temperature is -5℃(+23°F).
Introduction
Runchen Industry Co., Ltd. is a professional Ice-cream solutions provider backed up by an excellent team of qualified experienced engineers with many years' practical experience in the ice cream industry, either ice cream equipment manufacturers or ice cream factories.
Runchen mainly provides services for ice cream factories in below areas: 1) making and selling standard and customized ice cream manufacturing equipment 2) ice cream factory process and layout design 3) service facility capacity design 4) engineering installation.
technology
The freezer is made up of stainless steel which is durable and meets food hygiene standards. Stainless steel has advantages like corrosion resistance, easy-cleaning, and long-term durability so it is widely applied in food processing equipment.
