Technical Parameter
|
Technical items |
Parameters |
Remarks |
|
Built-in compressor |
4.5 KW |
|
|
Refrigerant gas |
Standard R507 |
|
|
Content of the refrigerant |
2.8 Kg (6.17 LB) |
|
|
Condensing medium |
Water |
|
|
Mixing motor |
0.75 KW |
|
|
Hybrid motor |
0.37 KW |
|
|
Total power |
6 KW |
|
|
Air consumption |
0.5 m³/h |
|
|
Compressed air consumption |
6 bar |
|
|
Compressed air mass, maximum moisture content |
2.5 g/m³ |
|
|
Condensed water consumption: water in water pipe |
≤+20℃ |
800 L/h |
|
Condensed water inlet connection |
Inner diameter 16mm hose |
|
|
Condensed water outlet connection |
Inner diameter 16mm hose |
|
|
Mixture feed tube, outside |
19 mm |
3/4" clamp |
|
Ice cream discharging tube, outside |
25 mm |
1" clamp |
|
Maximum overrun ratio |
100% |
Feature
- The maximum production capacity is 50 L/h.
- A continuous and automatic ice cream freezer.
- All function buttons are controlled by the HMI and easy to use.
- Operators can set parameters like the ice cream flow, overrun ratio, viscosity etc. through the HMI. Through calculating, the built-in PLC can automatic control functions of every part of the freezer to produce the needed ice cream product.
Advantage
- The automatic design greatly reduces labor costs.
- We have stock of A50L automatic and continuous ice cream freezer, so the machine can be shipped quickly.
- Automated design can reduce labor costs and make operations convenient and fast.
- Powerful features and low price.
Application
- Suitable for manufacturers who need to produce 50L ice cream per hour.
- Suitable for manufacturers who need to control the production process by the HMI.
- Suitable for manufacturers who need to produce ice cream automatically without manual production.
Packing
The freezer, which is designed as a self-sealing machine, is usually packaged in a wooden box and fixed on the baseboard. The unpacking operation should be processed near the installation site.
The wooden box which carried the A50L automatic and continuous ice cream freezer should be moved near to the operating site as far as possible when receiving. The transport of the freezer can be done by forklift or crane (place the lifting structure under the baseboard).
The wooden box can be transported by forklift (1) or crane (2).
FAQ
Q: What is the best ambient temperature?
Q: What is the best ambient humidity?
Refrigeration system
The freezing cylinder is refrigerated by the Freon compressor brought by itself, and the stirring scraper located in the freezing cylinder mixes the air into the slurry, and then a stainless steel stirring scraper with a blade which continuously rotates at a certain speed along the inner surface of the freezing cylinder and finally the ice cream discharges out of the discharging pipe.
