Technical Parameter
|
Technical items |
Parameters |
Remarks |
|
Built-in compressor |
4.5 KW |
|
|
Refrigerant gas |
Standard R507 |
|
|
Content of the refrigerant |
2.8 Kg (6.17 LB) |
|
|
Condensing medium |
Water |
|
|
Mixing motor |
0.75 KW |
|
|
Hybrid motor |
0.37 KW |
|
|
Total power |
6 KW |
|
|
Air consumption |
0.5 m³/h |
|
|
Compressed air consumption |
6 bar |
|
|
Compressed air mass, maximum moisture content |
2.5 g/m³ |
|
|
Condensed water consumption: water in water pipe |
≤+20℃ |
800 L/h |
|
Condensed water inlet connection |
Inner diameter 16mm hose |
|
|
Condensed water outlet connection |
Inner diameter 16mm hose |
|
|
Mixture feed tube, outside |
19 mm |
3/4" clamp |
|
Ice cream discharging tube, outside |
25 mm |
1" clamp |
|
Maximum overrun ratio |
100% |
Feature
- The maximum production capacity is 50 L/h.
- The hard ice cream machine adopts an efficient compressor which results in a high refrigeration effect.
- All function buttons are controlled by the HMI and easy to use.
- Operators can set parameters like the ice cream flow, overrun ratio, viscosity etc. through the HMI. Through calculating, the built-in PLC can automatic control functions of every part of the freezer to produce the needed ice cream product.
Advantage
- The automatic design greatly reduces labor costs.
- We have stock of A50L automatic and continuous ice cream freezer, so the machine can be shipped quickly.
- Automated design can reduce labor costs and make operations convenient and fast.
- Easy operation, easy to maintain and low price.
- A compact design and relatively inexpensive manufacture.
Application
The A50L hard ice cream machine is mainly applied in industrial fields such as frozen food factories, large ice cream factories, popsicle factories, ice cream processing factories, etc.
Packing
The freezer, which is designed as a self-sealing machine, is usually packaged in a wooden box and fixed on the baseboard. The unpacking operation should be processed near the installation site.
The wooden box which carried the A50L automatic and continuous ice cream freezer should be moved near to the operating site as far as possible when receiving. The transport of the freezer can be done by forklift or crane (place the lifting structure under the baseboard).
The wooden box can be transported by forklift (1) or crane (2).
FAQ
Q: What is the production capacity of the A50L automatic and continuous freezer?
Q: What is the size of the A50L automatic and continuous freezer?
Q: What is the power consumption of the A50L automatic and continuous freezer?
Q: What's the difference between A50L automatic and continuous freezer and N50L continuous freezer?
Set output
Set overrun ratio
Set viscosity of ice cream
Start to produce
Control the formula
Alarm display
Introduction
Runchen Industry Co., Ltd. is a professional Ice-cream solutions provider backed up by an excellent team of qualified experienced engineers with many years' practical experience in the ice cream industry, either ice cream equipment manufacturers or ice cream factories.
Runchen mainly provides services for ice cream factories in below areas: 1) making and selling standard and customized ice cream manufacturing equipment 2) ice cream factory process and layout design 3) service facility capacity design 4) engineering installation.
technology
The refrigeration system of the hard ice cream machine adopts Freon as the refrigerant. The Freon refrigerant is conducive to reduce the temperature efficiently to meets the standards of ice cream freezing.
